RM95.00
Out of stock
Feature
– Smart protection at ohm range
– Null DCV
– Gilded Test Lead
– Special circuit for testing at Max. 20mohm just with 1.5v batteries
Specification
– Capacitance test with optional tool kit (CT-1)
– C1: 100pF ~ .025uF/ 2.5uF/25uF (±3.0% F.S)
– C2: big capacitor, up to 2000uf. Directly via tester jacks
– Decibel test: -20 ~ +62dB with an external polyester capacitor 0.2uF/400v
– Battery test: 1.5V
– Leakage current & diode test
– Transistor & LED test via optional special hFE socket
– High input impedance: DC 20kohm/V, AC9k ohm/V
– Strong magnet pivot – Jewel movement built-in
– Compact soft protective holster alongside
– Perfect overload protection including two fact-acting fuses 0.5A & 10A
– Adjustable rear tilt stand device with place hook-up
– Dimension & weight: 160 x 105 x 40mm & 325g approx
Power supply: AAA Size 1.5V 2pcs
Overvoltage catergory CAT III 600V, CAT II 1000V
DC voltage: 0.1/2.5/10/50/250/1000v ±4% of full scale
Null DC Voltage: ±5V / ±25V ±5% of full scale
AC voltage: 10/50/250/1000V ±5% of full scale
DC current: 0.05/2.5/25/25mA, 10A ±4% of full scale
Resistance: x1, x10, x10, x1k (C1), x10k (0.2 ~ 20Mohm) ±3% of scale length
Weight | 0.3 kg |
---|
